The ELIOS 3 is the latest generation of indoor/confined space UAV specifically designed for flights inside of GPS-denied environments. Building on the success of the generation 2, the ELIOS 3 encompasses crash-resilience, intuitiveness, reliability and precision indoor inspection. Optical flow stabilisation sensors are now replaced with state-of-the-art 3x computer vision cameras that anchors onto 21 anchor points during flight, maintaining the flight stability regardless of the environment. The legacy cage comes together with the UAV and is now 480mm wide, 380mm in height.
The new LiDAR payload on the UAV also assists pilots with live 3D mapping, providing better spatial awareness, mapping the flight space and providing flight trajectory while in operation. The ELIOS 3 also stores data captured by the LiDAR, enabling operators/asset owners to extract the LiDAR data and enhance the model using GeoSLAM or any other software compatible with LiDAR files. The accuracy of the LiDAR data is about ±2cm using GeoSLAM, and ±10cm when using the proprietory Inspector 4.0. For visual inspections, the 4k resolution camera of the ELIOS 3 captures crisp, sharp images, enabling the operator to obtain optimal information of the assets’ conditions.
Designed to be future-proofed with modular capabilities available in the coming months, the ELIOS 3 was built to further enhance your inspection capabilities using various industrial payloads suitable for different types of inspections. Full autonomous flight, NDT techniques and even outdoor flights will be part of the ELIOS 3 capabilities in the upcoming development roadmap releases.
Dimensions | 480mm Width, 380mm Height |
Motors | 4 fast reversing electric brushless motors |
Propellers | 4 propellers, 5 inches |
Max Flight Time | 9.2 minutes with LiDAR payload 12 minutes without LiDAR payload |
Battery Capacity | 4,350 mAh |
Flight Control Sensors | IMU, magnetometer, barometer, lidar, 3 computer vision camera and ToF distance sensor |
Max Transmission Distance | Up to 500m in direct line of sight Optional Range Extender for further distances |
Materials | IMU, magnetometer, barometer, lidar, 3 computer vision camera and ToF distance sensor |
Fail Safe | Auto-landing on signal lost |
Max Ascent Speed | 2 m/s; 6.6 ft/s |
Max Descent Speed | 2 m/s; 6.6 ft/s |
Max Speed | 2 m/s (Assist mode); 6.6 ft/s 5 m/s (Attitude mode); 16.4 ft/s 7 m/s (Sport mode); 23 ft/s |
Ingress Protection | Splash & dust resistant design, equivalent to IP44 |
Operating Temperature | 0°C to 50°C ; 32°F to 122°F |
Type | High-efficiency LEDs for even lighting in front, top & bottom Optimized for low impact of dust on picture quality |
Control | From remote controller, adaptive light beam controlled by camera pitch |
Modes | Normal Mode Dustproof Lighting Selective/Oblique lighting |
Light Output | 10k lumens (Standard) 16k lumens (Boost Mode) |
Battery Type | LiPo 6S HV Smart Battery: – LED, button and user interface – Improved safety during charge cycle – Accurate state-of-health and state-of-charge estimation – Plug-and-play charging – Self-balancing – Storage self-discharge – Cycle counter – Battery ID |
Battery Life Time | 50 flights |
Charging Time | 1 Hour |
Nominal Voltage | 22.8 V |
Rated Capacity | 4,350 mAh |
Operating Temperature | 10 – 40°C ; 50°F – 104°F |
Compliance | Approved for carry-on luggage. Complies with IATA Dangerous Good Regulation. |
Image Sensor | 1/2.3″ CMOS Effective Pixels: 12.3 M Sensitivity: Optimized for low light performance |
Photo Formats | JPG |
Video Formats | MOV |
Video Recording Resolutions | 4K Ultra HD: 3840 x 2160 @ 30 fps FHD: 1920 x 1080 @ 30 fps |
Video Streaming Resolution | FHD: 1920 x 1080 @ 30 fps |
Movie Field of View (FOV) | 114° horizontal, 130.8° diagonal |
Photo Field of View (FOV) | 118.8° horizontal, 148.6° diagonal |
Total Vertical Field of View (FOV) | approximately 260° including camera tilt |
Camera Pod Tilt | 180° |
Lens Depth of Field (DOF) | 2.71 mm focal length; fixed focus |
Storage Media | MicroSD card on board aircraft, up to 128 GB |
LiDar Payload | Ouster OS0-32 beams sensor |
